Designbotic Terrain
by DesignboticAutodeskFree
Imports selected ESRI grid data into Revit as a geolocated toposurface.
PRICINGFree
DEPLOYMENTDesktop
CATEGORYData Exchange
UPDATED ON MARKETPLACE
What it does
Designbotic Terrain imports ESRI grid files in .asc format into Autodesk Revit 2020–2024. A geolocated .dxf plot can set the project survey point, after which the tool positions and trims the terrain before loading it into Revit. It can also import ESRI grid files without geolocation or cropping.
Key capabilities
from the Autodesk App Store listingESRI grid import
Imports ESRI grid files in .asc format into Revit.
Geolocated toposurfaces
Creates a geolocated Revit toposurface from ESRI grid data.
Terrain area selection
Loads only the required portion of an ESRI grid file.
DXF survey positioning
Uses a geolocated .dxf plot to adjust the project's survey point.
Terrain trimming
Positions and trims the terrain surface before loading it into Revit.
In the catalog
143 plugins in Revit · Data Exchange
Price distribution: 64 free, 2 freemium, 77 paid
Pricing & deployment
Platform
Autodesk
Product
Revit
Deployment
Desktop
Pricing
Free
