Custom Screw Creator
by Fabian SchurigAutodeskFree
Create cylinder-head screws by setting dimensions and selecting preset values.
PRICINGFree
DEPLOYMENTNot published
CATEGORYDesign & Engineering
UPDATED ON MARKETPLACE
What it does
Creates a cylinder-head screw from configurable parameters or preset values. Parameters include screw name, head and body dimensions, hexagon dimensions, fillet radius, thread length, and chamfer distance.
Key capabilities
from the Autodesk App Store listingScrew naming
Sets the name of the screw body.
Head dimensions
Defines the cylinder head diameter and height.
Body dimensions
Defines the body shaft diameter and length.
Hexagon settings
Sets the inner hexagon diameter and the height of the hexagon cut.
Edge parameters
Sets the fillet radius and the chamfer distance on the body shaft.
Thread length
Defines the length of the thread.
Preset values
Creates a screw by selecting preset parameter values.
