curves2polyline
by CAD100AutodeskPaid
Joins lines, arcs, splines, and polylines into 2D polylines.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYProductivity & Utilities
UPDATED ON MARKETPLACE
What it does
Joins individual lines, arcs, splines, 2D polylines, and 3D polylines into 2D polylines. Settings cover Z-level, width, fuzzy distance, spline precision, and retaining the original objects.
Key capabilities
from the Autodesk App Store listingCurve joining
Joins individual lines, arcs, splines, 2D polylines, and 3D polylines into 2D polylines.
Z-level setting
Provides a setting for the Z-level.
Width setting
Provides a setting for width.
Fuzzy distance
Provides a fuzzy-distance setting.
Spline precision
Provides a setting for spline precision.
Object retention
Provides an option to keep the original curve objects.
In the catalog
1,097 plugins in Productivity & Utilities
Price distribution: 389 free, 19 freemium, 689 paid
Pricing & deployment
Platform
Autodesk
Deployment
Desktop
Pricing
Paid
