Box Joint
by Mark SuskaAutodeskFree
Create CNC-friendly box and finger joints.
PRICINGFree
DEPLOYMENTDesktop
CATEGORYManufacturing & CAM
UPDATED ON MARKETPLACE
What it does
Box Joint creates box and finger joints for CNC cutting. The joint appears as an editable timeline feature, recomputes when earlier dependent bodies change, and includes axial and lateral clearance parameters.
Key capabilities
from the Autodesk App Store listingEditable timeline feature
The Box Joint appears as a single feature that can be edited after creation.
Timeline recomputation
The joint recomputes when dependent bodies earlier in the timeline change.
Three-axis CNC cutting
The joint can be cut flat from one side on a 3-axis CNC machine.
Clearance parameters
The add-in provides clearance parameters for axial and lateral directions.
Use cases
- Create box designs with box or finger joints.
- Create flowerpot designs with box or finger joints.
In the catalog
114 plugins in Manufacturing & CAM
Price distribution: 48 free, 66 paid
Pricing & deployment
Platform
Autodesk
Deployment
Desktop
Pricing
Free
