BIM-IT Pipe
by BIM-ITAutodeskPaid
Automates pipe modeling and documentation work within Autodesk Revit.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYDesign & Engineering
UPDATED ON MARKETPLACE
What it does
BIM-IT Pipe contains Revit tools for pipe tagging, positioning, splitting, visibility control, and insulation. It can place tags for pipes and branches, adjust pipe elevations and spacing, set clearances, and align section views. Other tools isolate pipe runs by system type, restore their visibility, and apply insulation rules based on pipe size and system type. The vendor states that the app uses a custom installer instead of the standard App Store installer.
Key capabilities
from the Autodesk App Store listingPipe Size Tagging
Places a pipe-size label near each spot elevation in the active Revit view, with selectable label types and offset settings.
Branch Tagging
Labels the pipes in a selected branch above a chosen spot elevation and arranges the labels vertically in pipe order.
Elevation Matching
Sets the elevations of selected pipes to match the first selected pipe at its centerline, upper, or lower elevation.
Equal Pipe Spacing
Repositions selected pipes at a specified equal distance while leaving the first pipe fixed.
Pipe Clearance Rules
Repositions pipes to meet defined clearances, including insulation, with options based on pipe size and insulation thickness.
Branch Splitting
Divides several pipes in a branch from a picked point or reference line using a selected direction.
System Run Isolation
Shows pipe runs for selected system types and provides a command to restore visibility for all pipe runs.
Insulation Application
Adds insulation according to user-defined pipe-size and system-type criteria and produces a status report for the rules.
Who it's for
BIM, MEP, and plumbing engineers.
How it compares
AutoInsulate applies reusable insulation rules based on system type and size range, while BIM-IT Pipe also provides pipe tagging, elevation, spacing, clearance, splitting, isolation, and section-view tools. Greater BIM works with pipes as well as ducts, cable trays, and conduits by bending them at specified angles, while BIM-IT Pipe provides the pipe tagging, insulation, isolation, and layout tools described in its listing.
| Name | Pricing | Deployment | Updated |
|---|---|---|---|
| this plugin | Paid | Desktop | |
| AutoInsulate | Paid | Desktop | |
| Greater BIM | Paid | Desktop |
