B3D Flow Lines
by Boceto3DAutodeskPaid
Create organic flow lines and optional 3D fins on curved surfaces in Fusion 360.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYDesign & Engineering
UPDATED ON MARKETPLACE
What it does
B3D Flow Lines creates organic lines across curved surfaces in Fusion 360 using a seeded field in the surface UV space. Lines can be converted into fins with fixed thickness and loft height. Controls set line spacing, length and curl. The add-in provides progress tracking, preview options and timeline integration.
Key capabilities
from the Autodesk App Store listingFlow line creation
Produces lines whose paths follow variations in a generated surface field.
3D fin conversion
Converts lines into fins with fixed thickness and loft height.
Line controls
Provides settings for line spacing, length and directional curl.
Curved surface mapping
Places generated lines across complex curved bodies.
Preview and progress
Shows operation progress and offers real-time preview options.
Timeline integration
Connects its operations with the Fusion 360 timeline.
Use cases
- Industrial designers can add aerodynamic ridges or textured grips to products.
- 3D printing enthusiasts can create biophilic patterns on vases and lampshades.
- Sculptors and concept artists can generate organic textures.
Who it's for
Industrial designers, 3D printing enthusiasts, sculptors and concept artists.
In the catalog
513 plugins in Fusion 360 · Design & Engineering
Price distribution: 158 free, 4 freemium, 351 paid
Pricing & deployment
Platform
Autodesk
Product
Fusion 360
Deployment
Desktop
Pricing
Paid
More from Boceto3D
Similar plugins in Fusion 360 · Design & Engineering
View all 513 →
ProtoTech's FBX Exporter for Autodesk® Fusion®
Exports Fusion 360 design models to FBX files with color, polygon reduction, orientation, and export-setting options.
ProtoTech Solutions and Services Pvt. LtdPaid
ProtoTech's GLTF Exporter for Fusion® - Trial
Exports Fusion 360 solid bodies and sketches to GLTF or GLB files.
ProtoTech Solutions and Services Pvt. LtdPaid
ProtoTech's FBX Exporter for Fusion® - Trial
Exports Fusion 360 design models to FBX files with adjustable export settings, polygon reduction, color preservation, and orientation control.
ProtoTech Solutions and Services Pvt. LtdPaid
What the vendor says
«B3D Flow Lines is a powerful design tool that generates organic flow lines by integrating streamlines over a seeded value-noise field in the surface UV space. It can instantly turn each line into a constant-thickness fin, allowing you to create beautiful aerodynamic or biophilic designs on any complex curved body.»
