B's 墙体自动创建洞口 2019（付费版）
by ブレンスタッフ株式会社AutodeskPaid
Creates openings in walls adjacent to a selected wall, using its doors, windows, and openings as references.
PRICINGPaid
DEPLOYMENTDesktop
CATEGORYDesign & Engineering
UPDATED ON MARKETPLACE
What it does
Creates openings in walls adjacent to a selected wall based on the doors, windows, or openings in that wall. It supports separately modeled main, substrate, and finish walls rather than compound walls. The paid version can create or delete openings in batches by specified level and generate a list of newly created openings.
Key capabilities
from the Autodesk App Store listingIndividual opening creation
Creates openings in walls adjacent to a selected wall.
Batch opening creation
The paid version selects walls whose level and base constraint match a specified level, then creates openings in adjacent walls.
Batch opening deletion
The paid version selects automatically created openings whose level matches a specified level and deletes them.
Opening list generation
Generates a list of newly created openings and highlights a selected opening in the current view.
Use cases
- Create corresponding openings in separately modeled substrate and finish walls after openings have been created in a main wall.
- Check the number and sizes of newly created openings using the generated list.
In the catalog
513 plugins in Design & Engineering
Price distribution: 158 free, 4 freemium, 351 paid
Pricing & deployment
Platform
Autodesk
Deployment
Desktop
Pricing
Paid
