AiCorb Modeling Function
by AiCorb by ObayashiAutodeskFree
Applies facade image designs to Conceptual Mass surfaces in Revit.
PRICINGFree
DEPLOYMENTDesktop
CATEGORYDesign & Engineering
UPDATED ON MARKETPLACE
What it does
Reads a facade image and identifies panel and window design parameters. It registers the results in a local design palette and applies them to a Curtain Panel Family template. The facade design can then be reproduced on a Divided Surface of a Conceptual Mass in Revit.
Key capabilities
from the Autodesk App Store listingFacade image reading
Reads facade images using an AI server to identify design parameters.
Panel parameter recognition
Recognizes panel aspect ratio and panel color from a facade image.
Window parameter recognition
Recognizes window aspect ratio, frame thickness, and frame depth.
Design palette storage
Registers recognition results in the local environment's design palette.
Conceptual Mass application
Applies facade designs to Divided Surfaces of Conceptual Mass volumes.
Use cases
- Creates 3D models from design concepts sketched or generated using AI.
- Applies a saved facade design to a current volume model during design exploration.
In the catalog
72 plugins in Revit · Design & Engineering
Price distribution: 22 free, 2 freemium, 48 paid
Pricing & deployment
Platform
Autodesk
Product
Revit
Deployment
Desktop
Pricing
Free
