ダイテックリンク2022
by 株式会社ダイテックAutodeskFree
Transfers drawing data between Revit 2022 and CADWe'll Tfas, CADWe'll Tfas E, or CADWe'll Linx.
PRICINGFree
DEPLOYMENTDesktop
CATEGORYData Exchange
UPDATED ON MARKETPLACE
What it does
This Revit 2022 add-in exchanges drawing data with CADWe'll Tfas, CADWe'll Tfas E, and CADWe'll Linx through dedicated files. Ducts, pipes, equipment, and fixtures created in Tfas or Linx can be transferred to Revit 2022 while retaining their connection states. The same elements created in Revit 2022 can be transferred to Tfas or Linx with their connection states retained. The application uses a custom installer rather than the standard App Store installer.
Key capabilities
from the Autodesk App Store listingDedicated file exchange
Transfers drawing data between Revit 2022 and CADWe'll Tfas, CADWe'll Tfas E, or CADWe'll Linx using dedicated files.
Connection state retention
Retains the connection states of ducts, pipes, equipment, and fixtures during transfers.
Bidirectional transfers
Transfers supported drawing elements from Tfas or Linx to Revit 2022 and from Revit 2022 to Tfas or Linx.
In the catalog
143 plugins in Revit · Data Exchange
Price distribution: 64 free, 2 freemium, 77 paid
Pricing & deployment
Platform
Autodesk
Product
Revit
Deployment
Desktop
Pricing
Free
